SVL97-3
The newly introduced SVL97-3 takes the place of the established SVL97-2 and is Kubota’s latest track loader, offering a comprehensive selection of innovative features that boost performance and comfort. With a robust 96.4HP Kubota engine, the Kubota SVL97-3 offers a bucket breakout force of 3468KG and a lifting capacity of 2394KG, along with delivering unparalleled comfort and performance to handle any job effortlessly. Delivering remarkable versatility, the hi-flow hydraulics provide 156.0 l/min, allowing for the use of the largest attachments, from tree mulchers to road profilers. The newly introduced features include a one-piece cabin, advanced hydraulic system, a 7-inch LCD touchscreen with keyless ignition and an integrated reverse camera, an updated engine layout, and additional options including Heated Air Suspension seat and KSR (Kubota Shockless Ride). The standard and high-flow models continue to allow the use of a wide range of options from our SSV and SVL performance-matched attachments lineup.
Product Features
One-Piece Sealed Pressurised Cabin
The SVL97-3 continues to provide a fully comfortable experience for its operator that features a fully sealed, integrated pressurised cabin that blocks the ingress of dirt, dust, water, and debris, creating a clean operational environment for the user.
This model is now fitted with a Heated Air Seat, LED work lights and improved HVAC performance with outstanding air flow for cooling and Heating regardless of the outside temperature.
Improved Technology
The SVL97-3 now has a colour LCD touchscreen that shows a wide range of functions including:
- Machine Status
- Hyd Oil Temp
- Coolant Temp
- Fuel Level
- Attachment Performance Monitor
- AUX Pressure Level
- DEF Level and is integrated with the Rear View Camera
- Keyless Engine Start
- Bluetooth Radio
Maintenance Simplified
The SVL97-3 allows for easier maintenance with the following features:
- A new swing out radiator
- Welded Mainframe
- Welded Under Carriage
- Triple Flange Rollers
- Tilt up Cabin
- Improved Side Panel for cleaning and debris removal
Kubota Shockless Ride
Now including the Kubota Shockless Ride system (KSR), the loader ride control system assists in reducing load spillage on rough terrain.
Powerful Hydraulic System
The SVL97-3 is now equipped with a Load Sensing System and control valve to provide exceptional pushing & driving force needed to do the work even while operating simultaneous attachments.
The maximum Oil Flow is now 156l/m and can be controlled via the LCD Touch Panel for the attachments being used and ensures optimal flow rates.
An Electronic Travel Torque Management System gives you more power when needed by ensuring the ECU constantly monitors the machine loads and optimises the Hydraulic pump output for smoother operation when needed.
Traveling Features
Now fitted with Auto Shift that allows the machine to smoothly drive into large piles or push heavy loads but still gives outstanding turning performance.
The ECU constantly monitors the traction load and automatically shifts down if this load gets to high, but before the unit starts to lose traction, and once the traction load reduces, it shifts backup for high speed operation.
Operators can now also change the sensitivity of their machines track response through the LCD panel giving a choice of 3 settings: Mild, Normal & Quick.
Specifications
| Name | SVL97-3 |
|---|---|
| Engine Type | Water Cooled |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Engine Model | Kubota V3800-TIE5-L |
| Engine Net | 94.9 HP |
| Engine Gross | 96.4 HP |
| Displacement | 3769 cc |
| Rated Speed | 2500 rpm |
| Name | SVL97-3 |
|---|---|
| Track Width - Standard | 450 mm |
| Ground Pressure Cab - Standard Track | 4.7 psi |
| Track Roller (Per Side) | 5 |
| Track Ground Contact Length | 1667 mm |
| Traction Force | 5976 kg |
| Min. Ground Clearance | 278 mm |
| Name | SVL97-3 |
|---|---|
| Aux Hydraulic Flow - High | 156 l/min |
| Loader Hydraulic Pressure (Per cm2) | 249.8 kgf |
| Name | SVL97-3 |
|---|---|
| ROC - 35% Tipping Load | 1569 kg |
| Tipping Load | 4483 kg |
| Breakout Force - Bucket | 3468 kg |
| Breakout Force - Lift Arm | 2394 kg |
| Lift Arm Path | Vertical |
| Name | SVL97-3 |
|---|---|
| Low | 8.9 km/h |
| High | 13.5 km/h |
| Name | SVL97-3 |
|---|---|
| Length (w/out Bucket) | 3141 mm |
| Width - Standard Track | 1962 mm |
| Height | 2112 mm |
| Operating Weight - Cab | 5411 kg |
| Name | SVL97-3 |
|---|---|
| Fuel Reservoir | 115.7 l |
| Hydraulic System | 70 l |
| Hydraulic Tank | 40.2 l |
| Name | SVL97-3 |
|---|---|
| Cab | YES |
| Open Cab | NO |
| Front Sliding Window | YES |
